Tecnam P2002 JF - Stabilator Setting

Page 201 2
nd
Edition – Rev 0
27-50
RUDDER – DESCRIPTION AND OPERATION
1. STABILATOR SETTING
In order to find the stabilator’s ”zero” the aeroplane must be previously
longitudinally leveled. Place a shim 19mm thick over the stabilator’s rear spar
and place the level over the shim and the stabilator’s tubular spar, then level
the stabilator.
Figure 22. – Stabilator setting
