Tecnam P2002 JF - Maintenance Practices

Page 200 2
nd
Edition – Rev 0
21-20
VENTILATION – MAINTENANCE PRATICE
MAINTENANCE PRACTICES
This Chapter contains the following maintenance tasks description:
 Cold air diffuser replacement
The following procedure applies to both LH and RH diffusers.
Step no.
Task description
Additional info &
References
1.
Remove serflex clamp and disconnect air hose from
the rear of diffuser;
You can easily access the
hose from the bottom of the
instrument panel.
2.
Unthread diffuser from its seat;
Strongly push diffuser
inward from its rear .
3.
Replace diffuser if necessary;
4.
Place the new/overhauled unit into seat;
Note tongues on diffuser’s
outer surface: push diffuser
until you hear “click”.
5.
Connect air hose to diffuser and fasten it by serflex
clamp.
