Tecnam P2002 JF - Fuel Tank Vent Hose; Tank Vent Connection

Page 4 2
nd
Edition – Rev 0
28-10
FUEL SYSTEM – DESCRIPTION AND OPERATION
Tank vent connection (fig 4.1) is located at the highest point of the inboard sidewall of each
fuel tank in order to expel the excessive vapors through a tube located at the each wing tips
(fig 4.2).
Figure 4.1. – Tank vent connection
Figure 4.2. – Fuel tank vent hose
