Tecnam P2002 JF - Flap Position Transmitter Replacement

Page 203 2
nd
Edition – Rev 0
27-30
FLAPS – MAINTENANCE PRACTICE
2. FLAP POSITION TRANSMITTER REPLACEMENT
Step
Task description
Additional info &
References
1.
Engage parking brake
2.
Make sure Master Switch is turned OFF.
3.
Open (15) inspection cap
See Chapter 06
4.
Remove fastener and disconnect transmitter connector.
Refer to Figures 18. and 19.
5.
Disconnect transmitter lever unscrewing bolt.
Refer to Figures 18. and 19.
6.
Record transmitter position on flap torque tube and
loosen serflex
7.
Remove ground wire from transmitter plate then remove
transmitter and replace it (if needed)
Refer to Figures 18. and 19.
9.
Position flap transmitter as recorded during removal.
10.
Position ground wire between serflex and transmitter
plate, tighten serflex, screw to lock. Connect transmitter
lever.
Refer to Figures 18. and 19.
NOTE: REPLACE ALWAYS THE SELF LOCKING NUTS WITH NEW ONES
11.
Connect transmitter connector and apply fastener then
close (15) inspection cap
See Chapter 06
12.
Set Master Switch ON and check the flap position.
13.
Perform an operational control: flap position, flap travel
limits
