ELT – MAINTENANCE PRACTICES
MAINTENANCE PRACTICES
This Chapter contains the following maintenance tasks description:
ELT Removal procedure
ELT Installation procedure
1. ELT REMOVAL PROCEDURE
ELT removal procedure
1.
Set Master Switch OFF
2.
Disconnect D-SUB connector from ELT unscrewing pivots
Refer to Fig.
10
3.
Disconnect BNC connector unscrewing ring nut and pulling it out
Refer to Fig.
10
4.
Pull velcro strap
5.
Remove ELT
2. ELT INSTALLATION PROCEDURE
ELT installation procedure
1.
Put ELT on support tray
2.
Lock with velcro strap
3.
Insert D-SUB connector and screw pivots
Refer to Fig.
9
4.
Insert BNC connector and screw ring nut
Refer to Fig.
9
5.
Perform transmitter test according to ELT CMM
