Tecnam P2002 JF - Power Generation; Generators; Generator Features

Page 1 2
nd
Edition – Rev 0
24-10
POWER GENERATION – DESCRIPTION AND OPERATION
24-10 POWER GENERATION
DESCRIPTION AND OPERATION
Generators
1. Built-in generator
2. External generator
Main features:
maximum power output (W)
250 @ 5800rpm
nominal voltage (V)
14±0.3
current limit (A)
28
maximum current output (A)
20
operational temperature range (°C)
- 25 ÷ 90
The generator is provided with an external solid state electronic full-wave rectifier/regulator.
The current vs rpm chart is shown below:
Figure 1. - Generator Features
