Tecnam P2002 JF - Stabilator Structure

Page 5 2
nd
Edition – Rev 0
03-00
AIRPLANE GENERAL DESCRIPTION
The horizontal empennage is an all-moving type (stabilator); its structure consists of a twin
spar to which six ribs are joined and it is covered by stressed aluminum alloy skin. The trim
tab completes the assy.
Figure 5: Stabilator structure
