Page 5 2
nd
Edition - Rev 0
79-10
OIL SYSTEM – DESCRIPTION AND OPERATION
Radiator
The oil radiator is installed on the front end of the engine cowling and it is con-
nected on the engine mount.
Figure 5. - Oil radiator
