Tecnam P2002 JF - Starter Relay Replacement

Page 203 2
nd
Edition – Rev 0
24-20
POWER DISTRIBUTION – MAINTENACE PRACTICE
2. STARTER RELAY REPLACEMENT
This procedure applies to starter relays.
Procedure
Step no.
Starter relay replacement
Task description
Additional info &
References
1.
Make sure that the Master Switch is set to OFF
2.
Make sure that no external power is provided
3.
Pull out battery breaker
4.
Open engine cowling (upper and lower panel)
5.
Remove relay electrical wires (3 items) extracting
sheathings.
Refer to figure below. Record
wires positioning
6.
Unscrew bracket screws and remove the relay
7.
Put in place new relay
8.
Fix the bracket screws
9.
Connect relay electrical wires relocating
sheathings.
Make reference to the
recorded wires positioning
10.
Perform functional test: start engine
Refer to AFM
11.
Close engine cowling (upper and lower panel)
