Tecnam P2002 JF - Annunciator Panel Lights Replacement

Page 205 2
nd
Edition – Rev 0
31-10
INDICATING SYSTEM –MAINTENACE PRACTICES
3. ANNUNCIATOR PANEL LIGHTS REPLACEMENT
Procedure
Step
no.
Task description
Additional info &
References
1.
Engage parking brake
2.
Set electric MASTER switch OFF
3.
Remove the instruments panel upper cover
4.
Remove all panel connections
Follow wires behind the
annunciator panel until you get
the three connectors and
disconnect them.
5.
Unscrew the attaching screws which fix the annunciator
panel to the aluminum panel
Hold firmly the annunciator
panel by hand during removal
- Refer to Figure 10.
6.
Unscrew the attaching screws which fix the lights to the
annunciator panel
Refer to Figure 11.
7.
Clear the light housing of the annunciator panel
8.
Apply a slight pressure, by suitable means, on both the
light cover sides in order to make the cover plugs release
Refer to Figure 12.
9.
Replace light
10.
Install the light cover
Make sure that plugs properly
fix cover to the housing.
11.
Installing the lights to the panel
12.
Fix the annunciator panel, inversely to steps 5 and 6
13.
Install the instruments panel upper cover
14.
Reset breaker IN and MASTER switch ON
15.
Restore annunciator panel connections and check for its
proper installation
