POWER DISTRIBUTION – TROUBLESHOOTING
Battery Bus
The battery bus is connected to the battery through a relay controlled by the Master Switch.
There is a 50 Amps breaker between the battery and the battery bus.
All systems are connected to battery bus.
Avionic BUS
The avionic BUS, furnish power to the following systems:
1
GMA 340
2
GNS 430w
3
GI 106 A
4
GTX 328
