INDICATING SYSTEM –MAINTENACE PRACTICES
The following indicators belong to the type in subject:
A panel
B panel
C panel
 Turn coordinator
 Directional gyro indicator
 Vertical speed indicator
 Altitude indicator
 Horizon
 Airspeed indicator
 ADF indicator
 VOR/ILS Indicator
 Fuel pressure indicator
 Chronometer
 Amp-meter
none
Step
Task description
Additional note
1.
Engage parking brake
2.
Set electric MASTER switch OFF
3.
Remove the instruments panel upper cover
4.
Remove all instrument hoses and connections
5.
Unscrew the attaching screws which fix the instrument to the
aluminum panel
Hold firmly the
instrument by hand
during removal
6.
Clear the instrument of the instrument panel
7.
Place into position the new/overhauled unit in correspondence
of the instrument panel cut-out
8.
Install the attaching screws which fix the instrument to the
aluminum panel
Hold firmly the
instrument by hand
during installation. Do
not over tighten
screws to avoid
instrument case
damage
9.
Install all instrument hoses and connections removed at step 5.
10.
Install the instruments panel upper cover
11.
Perform the final test
