Page 201
SUPPLEMENT S2
STABILATOR AND RUDDER- POST-SHIPMENT REASSEMBLY INSTRUCTION
1
st
Edition - Rev
1. STABILATOR PRE-INSTALLATION PROCEDURE
Step
no.
Stabilator pre-installation
procedure
Task description
Additional info &
References
1.
Check stabilator attachment points
free from
deformation, corrosion and cracks
2.
Check the Main bolt assemblies free from def-
amation and corrosion
2. S
TABILATOR INSTALLATION
Procedure
Step
no.
Stabilator installation
Task description
Additional info &
References
1.
Engage parking brake
2.
Make sure that Master switch is set to OFF
3.
Put right half stabilator on the torque tube
4.
Screw the RH stabilator attachment (Spacer,
washer, bolt, nut )
Refer to basic manual, ATA
20 for correct torque value
Refer to Figures 55.1. and
55.4.
5.
Put the left stabilator on torque tube and screw
the LH stabilator attachment
Refer to basic manual, ATA
20 for correct torque value
Refer to Figures 55.1.
and 55.4.
6.
Screw two screws on the rear of the stabilator Refer to Figures 55.2.
7.
Connect the trim tab to the stabilator
Refer to basic manual, ATA
55 and Figure 55.3.
