Page 208
SUPPLEMENT S2
WINGS- POST-SHIPMENT REASSEMBLY INSTRUCTION
Step
no.
Control cable and hoses
installation
Task description
Additional info &
References
7.
Connect the Pitot hoses between the wing and
fuselage of the system (LH side).
Pay attention to align the hoses of the fuselage
(with the placards), with the hoses of wing as
marked before.
(Connect the Pitot Heat connector, only if
‘VFR Night’ package is installed).
Refer to Figure 57.7.
8.
Connect stall warning device connector on RH
wing.
Refer to Figure 57.8.
9.
Install fairings between the wings and fuse-
lage
10.
Install the wing’s composite root-leading edge
11.
Install all cabin floor panels and all baggage
compartment panels
Refer to Figure 57.3.
12.
Install the seats (pilot and co-pilot)
Refer to chapter 12 in this
document
13.
Install the MLG and NLG fairings Refer to basic manual, ATA 32
