SUPPLEMENT SG-1
CHAPTER 34 - NAVIGATION
Page 7
Equipment location
Following picture shows the main components location inside the airplane.
Namely:
• GDU 620, located on the instrument panel;
• GRS 77 AHRS, located on the rear of baggage compartment;
• GMU 44, located under the vertical fin;
• GDC 74 Air Data Computer, located behind the firewall, in the RH side;
• GTP 59, located on the lower side of RH wing.
