AILERONS – DESCRIPTION AND OPERATION
AILERON CONTROL SYSTEM
FIG.
ITEM
DESCRIPTION
FIG.
ITEM
DESCRIPTION
A1
BELLCRANK LH
31
FWD AILERON CABLE
1
ANCHOR NUT
33
STOP NUT M6
2
SPACER
34
PULLEY
3
BALL BEARING BC4W10
35
STICK
4
BOLT HEX. HEAD M6 L=40 CR. 8.8
5
BELLCRANK LEVER
6
STOP NUT M6
7
PLAIN WASHER LARGE D=6
8
BOLT HEX. HEAD
9
JUNCTION
10
AILERON CONTROL ROD
11
JOINT
12
WASHER D=6
13
STOP NUT M5
14
WASHER D=5
15
BUSHING
16
BOLT HEX. HEAD M5 L=55 CR. 8.8
A2
PUSH-PULL ROD
17
TUBE
18
AILERON CONTROL ROD TERMINAL
19
POP RIVET 4.00
A3
ASSY AILERON CABLES ATTACHING ROD
AFT
20
JOINT
21
AFT AILERON CABLE
22
WASHER D=6
23
STOP NUT M6
24
BOLT HEX. HEAD M6 L=35 CR. 8.8
25
AILERON CABLE ATTACHING ROD
26
PULLEY
27
TURNBUCKLE
A4
ASSY AILERON CABLES FWD (LH-RH)
28
JOINT
29
CABLE PLATE
30
BOLT HEX. HEAD M6 L=35 CR. 8.8
