Page 207
SUPPLEMENT S4
WINGS - POST SHIPMENT ASSEMBLY INSTRUCTION
2
nd
Edition - Rev 0
5. CONTROL CABLES AND HOSES PRE-INSTALLATION PROCEDURE
Step
no.
Control cable and hoses pre-
installation
Task description
Additional info &
References
1.
Check cables are free from deformation, corro-
sion and cracks
2.
Check the bolts assemblies are free from de-
formation and corrosion
6. CONTROL CABLES AND HOSES INSTALLATION
This chapter contains the complete procedure for control cable and hoses installation.
Procedure
Step
no.
Control cable and hoses
installation
Task description
Additional info &
References
1.
Engage parking brake
2.
Make sure that Master switch is set to OFF
3.
Remove the protective cap and connect the fuel
system hoses (LH and RH side)
Refer to Figures 57.7. and
57.8.
4.
Connect the fuel quantity sensors (TELEVEL)
wiring and the position lights wiring (LH and
RH side).
Pay attention aligns the connectors with the
same placards.
Refer to Figures 57.7. and
57.8.
5.
Marks the Pitot hoses in the LH wing, and
connect this hoses to Pitot system
Make distinctions between
static and dynamic lines: a low
pressure compressed air can
help the lines distinction.
Note: the hoses in the fuselage
have a placard for the lines
distinction
6.
Install Pitot system in the bottom side of LH
wing
Refer to basic manual, ATA
34
