Tecnam P2002 JF - Page 947

Page 203
SUPPLEMENT S4
ENGINE - POST-SHIPMENT ASSEMBLY INSTRUCTION
2
nd
Edition - Rev 0
Step
no.
Power plant con-
trol rigging
Task description
Additional
info &
References
3.
Stroke adjustment.
 Remove airbox bowden cable
from air-box control lever
 Loosen nut
 Screw/unscrew rod end bearing
to adjust cable as needed
 Screw nut to lock position
 Connect bowden cable to con-
trol lever.
4.
Check carburetor heat control
stroke
CHOKE CONTROL RIGGING
1.
Connect choke bowden cable to
choke control lever
2.
Check choke control stroke
 Ensure that when
choke knob is
fully upward ,
choke control
lever reaches the
relative stop
screw (Refer to
Figure 77.3.)
 Ensure that when
choke knob is
fully downward ,
choke control
lever reaches the
relative stop
screw (Refer to
Figure 77.4.)
