TEEJET 5000 OPERATORS MANUAL FERTILISER DISTRIBUTOR, RAUCH BETA/DELTA
4.103
FERTILISER DISTRIBUTOR OPERATION
FORWARD SPEED:
The primary function under fertiliser distributor is
forward speed.
Forward speed is displayed in KPH with 1 decimal.
Forward speed is calculated from the signal from the
speed sensor selected in encode (wheel tractor, wheel
sprayer or radar).
SPREADER SECTION INDICATION:
The picture to the left shows a 2-section spreader with 1
section closed and 1 section open. The number of
sections can be changed in “ENCODE”.
The figure to the right indicates which calibration is
being used.
REQUIRED APPLICATION RATE:
The second function is the required application rate. If
there is a difference between the right and the left-hand
side, this will also be displayed.
An arrow is displayed on the left of the screen indicating
which way the regulating device is moving.
NOTE: Different application rates for the two sides
can only be achieved via the +/- % keys.
I
When the area override sensor is activated (not
counting area) “I” is displayed and all sections will
disappear.
FERTILISER SPREADER FUNCTIONS:
There are 2 different function sets in this menu. The
displayed set depends on whether automatic or manual
application control has been selected.
The following describes each function set individually.
