TEEJET 5000 OPERATORS MANUAL SLURRY SPREADER, ZUNHAMMER
7.45
SLURRY SPREADER: WITHOUT FLOWMETER
TON/M3: Slurry consumption in
ton/m3.
RPM 1: Revolutions per minute.
TON/M3: The amount of slurry spread since starting. This function works as
a trip counter, and can be deleted in “DATA/DELETE”. The total
counter is also found here.
RPM 1: The shaft speed of an axle is displayed here. Normally the RPM of
the distributor/macerator.
BOOM SECTIONS ON/OFF:
The picture shows that the spreader has 2 sections and
only one is open. The total number of sections must be
encoded in “DISTRIB. WIDTH”.
I
When the override sensor is activated (not measuring
area “I” is displayed.
