TEEJET 5000 OPERATORS MANUAL FERTILISER DISTRIBUTOR, OTHER TYPE
4.11
SYSTEM B PLUG
There are 2 system plugs on the back of the TeeJet 5000.
The System A plug is compatible with older TeeJet 5000 versions.
The System B plug is for new connections.
ACTIVE 0 VOLT: The individual sections are opened with 0V.
ACTIVE 12 VOLT: The individual sections are opened with 12V.
ON/OFF: ON: The system B plug is used.
OFF: The system B plug is not used.
WORK HOUR ON/OFF
Select whether the timer function is started/stopped manually via the function key
in the operation menu or by the selected implement sensor.
REVS. SENSOR
Encode the number of pulses per revolution given for
the individual sensors.
