TEEJET 5000 OPERATORS MANUAL GENERAL FUNCTIONS
2.27
TEST INPUT/OUTPUT, SEED DRILL
TEST INPUT OTHER TYPE NORDSTEN
TRAIL 1:
Signal from RPM sensor fitted to
the drill shaft.
Signal from RPM sensor fitted to
the drill shaft.
TRAIL 2:
Signal from RPM sensor fitted to
the tramlining clutches. When
the shaft is rotated slowly, the
status changes between HI and
LO and the number of impulses
is registered. The status
changes to LO if the shaft is
turned quickly
Signal from RPM sensor fitted to
the drill shaft drive motor.
TRAIL 4:
Signal from the hopper level
sensor (empty hopper).
Speed signal from sensor fitted
to the seed drill.
TRAIL 7:
Area override on/off signal from
sensor fitted to seed drill, i.e.
marking system or when the drill
is raised.
Area override signal from sensor
fitted to seed drill.
TRAIL 8:
Not used. Signal from RPM sensor fitted to
the fan or to the left clutch
(depending on drill model).
TRAIL 15:
Not used. Signal from the hopper level
sensor (empty hopper).
TRAIL 16:
Not used. Signal from RPM sensor fitted to
the right clutch.
BOM 1 – 12
Not used. Not used.
TEST OUTPUT
OUT 1:
Motor+ signal for when tramlines
are to be made.
Signal to control tramlining.
Pressing OUT 1 makes
tramlines.
OUT 2:
Not used. Signal to control the speed of
the drill shaft motor. Pressing
OUT 2 rotates the drill shaft.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
Not used. Not used.
