TeeJet 5000 - Test Input;Output, Slurry Spreader

GENERAL FUNCTIONS TEEJET 5000 OPERATORS MANUAL
2.30
TEST INPUT/OUTPUT, SLURRY SPREADER
TEST INPUT OTHER TYPE HYDRAULIC
TRAIL 1:
Signal from RPM 1 sensor, i.e.
distributor or macerator.
Signal from RPM sensor fitted to
the distributor.
TRAIL 2:
Signal from the slurry flowmeter
or signal from RPM sensor fitted
to a positive displacement pump.
Signal from flowmeter.
TRAIL 4:
Speed signal from sensor fitted
on the slurry spreader.
Speed sensor fitted on the slurry
spreader.
TRAIL 7:
Area override on/off signal from
sensor fitted on the slurry
spreader.
Area override on/off signal from
sensor fitted on the slurry
spreader.
TRAIL 8:
Not used. Signal from the RPM sensor
fitted to the pump.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Signal from boom section
switches via system B plug if
used.
Signal from boom section
switches via system B plug if
used.
TEST OUTPUT
OUT 1:
Signal to open the reg. Valve.
The application rate must
increase.
Signal to open the reg. Valve.
OUT 2:
Signal to close the reg. Valve.
The application rate must
decrease.
Signal to close the reg. Valve.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
Not used. Not used.
