TEEJET 5000 OPERATORS MANUAL GENERAL FUNCTIONS
2.31
TEST INPUT HORSCH ZUNHAMMER
TRAIL 1:
Not used. Not used.
TRAIL 2:
Signal from RPM sensor fitted
on the pump (flow).
Signal from RPM sensor fitted
on the pump (flow).
TRAIL 4:
Signal from the wheel sensor
fitted on the slurry spreader.
Signal from the wheel sensor
fitted on the slurry spreader.
TRAIL 7:
Signal from the implement
sensor fitted on the slurry
spreader.
Signal from the implement
sensor fitted on the slurry
spreader.
Note! Always active 0V
TRAIL 8:
Signal from the filling
mechanism.
Signal from the filling
mechanism.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Signal from the boom section
switches via the system B plug
(boom compensation) if this is
used.
BOOM 1-5:
Signal from the boom section
switches via the system B plug
(boom compensation) if this is
used.
BOOM 6: Alarm, no slurry flow.
BOOM 7: Alarm, High
pressure.
BOOM 8: Alarm, tank valve
closed.
BOOM 9: Alarm, fill pipe in.
BOOM 10: Full tank.
BOOM 11: Re-circulation.
TEST OUTPUT
OUT 1:
Signal to open the proportional
valve completely. When the key
is released the valve shuts.
Signal to open the proportional
valve completely. When the key
is released the valve shuts.
OUT 2:
Not used. Not used.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
Not used. Not used.
