FERTILISER DISTRIBUTOR, BREDAL TEEJET 5000 OPERATORS MANUAL
4.38
FERTILISER DISTRIBUTOR OPERATION
FORWARD SPEED:
The primary function under fertiliser distributor is
forward speed.
Forward speed is displayed in KPH with 1 decimal.
Forward speed is calculated from the signal from the
speed sensor selected in encode (wheel tractor, wheel
sprayer or radar).
AREA MEASUREMENT:
The worked area is displayed in Ha. Area is displayed
with 2 decimals from 0 to 99.99 ha. And thereafter with
1 decimal from 100 to 999.0 ha.
NOTE: a total counter for area can also be found in
“DATA/DELETE”.
FERTILISER DISTRIBUTOR FUNCTIONS:
KG/HA: Application rate in KG/HA.
KG: Fertiliser consumption in Kg.
KG LEFT: Total KG remaining in the hopper (the
amount must be encoded before start).
+XX%: Step dosage, increase.
-XX%: Step dosage, decrease.
DOSE RATE: Encoding the required application rate or
return to normal after using the step key.
