TEEJET 5000 OPERATORS MANUAL GENERAL FUNCTIONS
2.23
TEST INPUT/OUTPUT, FERTILISER SPREADER
TEST INPUT OTHER TYPE OTHER TYPE W. REG.
TRAIL 1:
Signal from shaft speed sensor
RPM 1
Signal from RPM sensor fitted to
discs. (RPM 1)
TRAIL 2:
Signal from shaft speed sensor
RPM 2, or signal from weigh
interface.
Signal from floor chain (RPM 2)
TRAIL 4:
Signal from speed sensor fitted
to trailed machines.
Signal from speed sensor fitted
to the spreader.
TRAIL 7:
Signal from area override sensor
fitted to the spreader, i.e.
open/close
Area override ON/OFF from the
spreader.
TRAIL 8:
Not used. Not used.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Signal from boom section
switches via system B plug.
(boom compensation), if used.
Signal from individual boom
sections via system B (boom
section compensation), if used.
TEST OUTPUT
OUT 1:
Not used. Signal to the regulating device.
OUT 2:
Not used. Signal to the regulating device.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2
Not used. Not used.
TEST INPUT BØGBALLE (E/EX & D/DZ) BREDAL
TRAIL 1:
Signal from shaft speed sensor. Signal from RPM 1 sensor.
TRAIL 2:
Not used. Signal from weigh cells.
TRAIL 4:
Speed signal from trailed
implement.
Signal from speed sensor fitted
to the driving wheel.
TRAIL 7:
Not used. Area override sensor fitted to the
arm of the driving wheel.
TRAIL 8:
Not used. Not used.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Error is displayed as no boom
interface is connected.
Error is displayed as no boom
interface is connected.
TEST OUTPUT
OUT 1:
Signal to close the gates. Signal to close the gate.
OUT 2:
Signal to open the gates. Signal to open the gate.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
POT 1 shows the position of the
actuator. Lowest value when the
gates are closed. POT 2 is not
used.
Shows the position of the
actuator. Lowest value when the
gate is closed, highest value
when the gate is open.
