GENERAL FUNCTIONS TEEJET 5000 OPERATORS MANUAL
2.24
TEST INPUT BREDAL (HYDRAULIC) BREDAL K RAMP
TRAIL 1:
Signal from RPM sensor fitted to
the spinning discs.
Signal from RPM sensor fitted to
the spinning discs.
TRAIL 2:
Signal from weigh cells. Signal from weigh cells.
TRAIL 4:
Speed signal from sensor fitted
to spreader wheel.
Speed signal from sensor fitted
to spreader wheel.
TRAIL 7:
Signal from RPM sensor fitted to
the hydraulic motor.
Signal from RPM sensor fitted to
the belt hydraulic motor.
TRAIL 8:
Not used. Signal from RPM sensor fitted to
the auger hydraulic motor.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Error is displayed as no boom
interface is connected.
Error is displayed as no boom
interface is connected.
TEST OUTPUT
OUT 1:
Completely opens the
proportional valve, when the key
is released the valve shuts.
Completely opens the belt
proportional valve, when the key
is released the valve shuts.
OUT 2:
Not used. Completely opens the auger
proportional valve, when the key
is released the valve shuts.
OUT 3:
Not used. Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
Not used. Not used.
