TEEJET 5000 OPERATORS MANUAL GENERAL FUNCTIONS
2.25
TEST INPUT RAUCH AERO RAUCH BETA/DELTA
TRAIL 1:
Not used. Signal from shaft speed sensor
(RPM 1).
TRAIL 2:
Signal from sensor on feed
rollers.
Not used.
TRAIL 4:
Signal from speed sensor fitted
to trailed machines.
Speed signal from trailed
implement.
TRAIL 7:
Area override on/off from the
machine.
Area override on/off signal from
implement.
TRAIL 8:
Not used. Not used.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used. Not used.
BOM 1 – 12
Error is displayed as no boom
interface is connected.
Error is displayed as no boom
interface is connected.
TEST OUTPUT
OUT 1:
Fully opens the reg. Valve
momentarily and the feed rollers
rotate at full speed. The valve
shuts and the feed rollers stop
instantly when the key is
released.
Signal to close the gate (left).
OUT 2:
Not used. Signal to open the gate (left).
OUT 3:
Not used. Signal to close the gate (right).
OUT 4:
Not used. Signal to open the gate (right).
POT 1 – 2:
Not used. Shows the position of the
actuators.
