TEST INPUT/OUTPUT, SPRAYER
TEST INPUT SPRAYER (OTHER TYPE) HOLDER
TRAIL 1:
Signal from pressure sensor Signal from pressure sensor
TRAIL 2:
Signal from sprayer
flowmeter. Turn the paddle
wheel by hand or let the
sprayer spray.
Signal from sprayer
flowmeter. Turn the paddle
wheel by hand or let the
sprayer spray.
TRAIL 4:
Signal from the wheel sensor
fitted on a trailed sprayer.
Signal from the wheel sensor
fitted on a trailed sprayer
TRAIL 7:
Signal from the sprayer’s
open/close function (main
on/off switch or manual main
valve).
Signal from the sprayer’s
open/close function (main
on/off switch or manual main
valve).
TRAIL 8:
Signal from filling flowmeter.
Turn the paddle wheel by
hand or fill the sprayer.
Signal from filling flowmeter.
Turn the paddle wheel by
hand or fill the sprayer.
TRAIL 15:
Not used. Not used.
TRAIL 16:
Not used Not used.
BOM 1 – 12
Shows, which of the
encoded boom sections, are
open or closed.
Shows, which of the
encoded boom sections, are
open or closed.
TEST OUTPUT
OUT 1:
Signal that controls the
pressure, and hence
increases the application
rate. Pressure will increase
as long as the key is
activated.
Signal that controls the
pressure, and hence
increases the application
rate. Pressure will increase
as long as the key is
activated.
OUT 2:
Signal that controls the
pressure, and hence
decreases the application
rate. Pressure will decrease
as long as the key is
activated.
Signal that controls the
pressure, and hence
decreases the application
rate. Pressure will decrease
as long as the key is
activated.
OUT 3:
Not used. Not used.
OUT 4:
Signal to the fill alarm or
valve, in conjunction with
automatic fill flow.
Signal to the fill alarm or
valve, in conjunction with
automatic fill flow.
POT 1 – 2
Not used. Not used.
