SPRAYER TEEJET 5000 OPERATORS MANUAL
3.6
AUTO/
MAN: Pressing this key selects automatic or manual application. If
manual operation is selected, “MAN” flashes in the lower part of
the screen and + and – appear as function keys.
+: Increased application. The application rate is increased as long as
this key is pressed. The speed at which the application rate
increases depends on the speed of the regulating system’s
operating speed (only displayed if “MAN” is selected).
-: Decreased application. The application rate is reduced as long as
this key is pressed. The speed at which the application rate
decreases depends on the speed of the regulating system’s
operating speed (only displayed if “MAN” is selected).
Pressing the “NEXT PAGE” key displays the first set of functions.
EXTRA TRACTOR FUNCTIONS IN THE SPRAYER PROGRAM
METRE IN TRACK: Distance driven in the present tramline.
METRE = Distance driven.
METRE START/
METRE STOP = Manual start and stop of the distance counter.
METRE IN TRACK
Distance driven in the current tramline. This function is used to, after refilling, find
the precise position in the tramline at which the sprayer ran empty. This function
works in conjunction with “REDUCE TRACK M”, which appears when the sprayer
is switched off. This function works in the following way:
Each time the sprayer is switched on again when starting a new tramline the
“METRE IN TRACK” counter starts from 0.
The computer remembers how far in the tramline has been driven, if the sprayer is
shut somewhere in the middle of the track. The function “REDUCE TRACK M” is
now displayed.
NOTE: Once the sprayer has been shut in the tramline, do not open the
sprayer again before the sprayer is full and the computer is ready as
follows:
Fill the sprayer again and drive to the start of the last tramline that was partially
sprayed.
Press “REDUCE TRACK M” and drive down the tramline. An alarm will sound and
“SPRAYER SOON TO BE OPENED” will be displayed 5 metres before the sprayer
should be opened. When the tractor reaches the position at which the sprayer
should be opened again, the computer will give another audible warning and
“START SPRAYING NOW” will appear on the display. The alarm will continue until
the sprayer is opened.
METRE
The distance driven in metres. Measured from the selected speed sensor and can
be started/stopped manually or with the override sensor. Select how in encode
under “METRE SWITCH”.
