GENERAL FUNCTIONS TEEJET 5000 OPERATORS MANUAL
2.28
TEST INPUT LEMKEN SIMBA
TRAIL 1:
Signal from the RPM sensor
fitted on the drill shaft.
Signal from RPM sensor fitted
on drill shaft 1
TRAIL 2:
Signal from the RPM sensor
fitted on the drill shaft drive
motor.
Signal from the RPM sensor
fitted on the drill shaft drive
motor (depending on drill
model).
TRAIL 4:
Speed signal from sensor fitted
to the seed drill.
Speed signal from sensor fitted
to the seed drill.
TRAIL 7:
Signal from the implement
sensor fitted on the drill.
Signal from the implement
sensor fitted on the drill.
TRAIL 8:
Signal from the RPM sensor
fitted on the fan.
Signal from the RPM sensor
fitted on fan 1.
TRAIL 15:
Signal from the hopper level
sensor fitted in the seed hopper
(empty tank).
Signal from the hopper level
sensor fitted in the seed hopper
(empty tank).
TRAIL 16:
Not used. Signal from the RPM sensor
fitted on fan 2.
BOM 1 – 12
Not used. BOOM 2: Signal from the
RPM sensor fitted
to drill shaft 2.
BOOM 8: Signal from the
RPM sensor fitted
on fan 2.
BOOM 1, 3-7, 9-12: Not used.
TEST OUTPUT
OUT 1:
Signal that controls the
tramlining for the left side of the
drill (tramlines are made on the
left side when OUT 1 is pressed)
Signal that controls the
tramlining (tramlines are made
when OUT 1 is pressed).
OUT 2:
Signal that controls the speed of
the drill shaft drive motor (the
drill shaft turns when OUT 2 is
pressed).
Signal that activates 1/2 and 1/1
working width.
OUT 3:
Signal that controls the
tramlining for the right side of the
drill (tramlines are made on the
right side when OUT 2 is
pressed)
Not used.
OUT 4:
Not used. Not used.
POT 1 – 2:
Not used. Not used.
