TEEJET 5000 OPERATORS MANUAL FERTILISER DISTRIBUTOR, RAUCH BETA/DELTA
4.105
STEP%: Step dose rate
RPM/POS: RPM for the spinning discs or the position of the actuator,
depending on which program has been selected (BETA or
DELTA).
AUTO/MAN: Changing between automatic or manual operation.
STEP%: Step dose rate.
NOTE: Only active in automatic drift.
The application rate can be increased or decreased by an encoded percentile
amount. The rate can be altered for both sides or the left-hand side or the right-
hand side by pressing the “NEXT PAGE” key, see the following pictures:
When used, the percentile increase or reduction flashes in the lower part of the
display.
NORMAL: Pressing the “NORMAL” key returns the application rate to
normal, regardless of how many steps the rate has been
increased or decreased by.
NOTE: The step dose rate screen is left by pressing the return
key.
RPM: This function is displayed in the DELTA-Program!
Pressing this key displays the speed of the spinning discs. The
minimum and maximum disc speed can be set as a warning under
“ENCODE”.
or
POS.: This function is displayed in the BETA-Program! This function is
displayed in the DELTA-Program on the next page.
The value displayed refers to the position of the actuator (the gate
opening).
AUTO/MAN: Pressing this key changes between automatic and manual
application control. During manual operation “MAN” flashes at the
bottom of the display.
Pressing the “NEXT PAGE” key displays the next functions.
