Boeing 767 - Page 172

B
DOVETAIL
SEAL
DISK
STAGE 1
(REF)
BOLT
(REF)
WEIGHT
BALANCE
(REF)
RETAINER
STAGE I SPACER
STAGE 1 BLADE
A
STAGE 1
DISK
SEE
B
SPINNER
FAN ROTOR
SPOOL
FAN ROTOR
STAGE
2
SEAL
(REF)
NUT
FAN BLADE
BLADE
STAGE 1
A
SEE
1148305-00-A
H11740 S00061422852_V1
Fan Rotor Assembly
Figure 402/72-31-00-990-806-G00 (Sheet 1 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 406
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
