Boeing 767 - Page 199

CF8-6205-00-A
270 ˚
180 ˚
90 ˚
A 211 ˚
1
A
280 ˚
0
U
8.0 MILS
0
R
8.3
1
U
6.7 MILS
1
0 ˚
X 48 ˚ CCW
51798 S00061422872_V1
Example of Polar Plot to Find the Correction Balance Weight
Figure 508/72-31-00-990-817-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 518
D633T1B7 Dec 22/2016
