CF8-6205-00-A
270 ˚
180 ˚
90 ˚
A 211 ˚
1
A
280 ˚
0
U
8.0 MILS
0
R
8.3
1
U
6.7 MILS
1
0
U
(EXTENDED)
CCW
X = 48 ˚
0 ˚
TRANSPOSED
R1
47810 S00061422873_V1
Example of How to Find Angle X By Transposition
Figure 509/72-31-00-990-818-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 519
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
