Boeing 767 - Page 224

A
1ST-STAGE DISK
1ST-STAGE DISK
RTV-108 OR RTV-103
SPACER
SPACER
RETAINER
FAN BLADE
FAN BLADE
A
SEE
1025925-02-A
G95632 S00061422895_V1
RTV Sealant Between Fan Blade Dovetail Slots
Figure 403/72-31-02-990-803-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 411
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
