2. ALL DIMENSIONS GIVEN IN INCHES WITH METRIC
1
UNITS IN PARENTHESES.
3. TIGHTEN LOCKNUT TO 70-90 POUND-INCHES
(7.9-10.2 N.M.)
THE FULL OPEN POSITION.
MEASURED WITH THE VANE LEVER ARMS IN
DIMENSION M
STAGE
MIN MAX
IGV 0.002 (0.05 MM)
0.002 (0.05 MM)
0.002 (0.05 MM)
0.002 (0.05 MM)
0.004 (0.10 MM)
0.004 (0.10 MM)
0.004 (0.10 MM)
0.004 (0.10 MM)
1
2
3
4
5
0.005 (0.13 MM)
0.017 (0.43 MM)
0.007 (0.18 MM)
0.019 (0.48 MM)
NOTES:
1. SPACER-TO-CASING CLEARANCES ARE TO BE
DIM. M
WASHER
LOCKNUT
ACTUATION
RING
THREADED
NUT
SPACER
CASING
(IGV, 1
THRU 4)
ACTUATION
RING LOCKNUT
WASHER
RTV
SPACER BACKED OFF AFTER
RTV IS APPLIED TO RING
RTV
ACTUATOR RING SPACER CLEARANCE
1
26096 S00061423037_V1
Spacer Nut Stabilization
Figure 604/72-35-00-990-805-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 611
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
