Boeing 767 - Page 355

ROD END BEARING
UNISON
RING
BOLT
VBV HINGE
ASSEMBLY
CLEVIS
BOLT
FAN FRAME NUT
VBV HINGE
WASHER
BELLCRANK
BOLT
FRAME
FAN
SEAL
VARIABLE BYPASS
VALVE (VBV)
FWD
(2 LOCATIONS)
E98133 S00061423065_V1
Stage 1 Blade Repair - VBV Door Assembly - Removal/Installation
Figure 805/72-35-00-990-813-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 818
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
