Boeing 767 - Page 72

CF8-6948-00-C
(20.32 mm)
(20.32 mm)
FORWARD EDGE OF THE
FORWARD EDGE OF THE
A-A
LEADING GILL HOLE CONVEX (SUCTION) SIDE
CONCAVE (PRESSURE) SIDE
TRAILING EDGE
0.800 INCH
0.800 INCH
LEADING GILL HOLE
LEADING EDGE
FWD
INNER FORWARD FLANGE
OUTER FORWARD FLANGE
TRAILING
EDGE SLOTS
A A
PLATFORM
INNER
NOSE HOLES
GILL HOLES
25350 S00061422719_V1
1st-Stage High Pressure Turbine Nozzle Vane Inspection
Figure 611/72-00-00-990-819-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 639
D633T1B7 Aug 22/2017
