MATERIAL
IS GONE
DIMENSION A
MATERIAL
IS GONE
DIMENSION A
DIMENSION B
DIMENSION B
CONNECTED CRACK
CIRCUMFERENTIAL
CRACK
SHROUD END
CIRCUMFERENTIAL CRACKS
AXIAL CRACKS
RADIAL CRACKS
FORWARD WALL
SEAL SLOT
24-PIECE SEGMENT SHROUD
AXIAL CRACKS
RADIAL CRACKS
FORWARD WALL
SEAL SLOT
SHROUD END
48-PIECE SEGMENT SHROUD
CONNECTED CRACKS
60900 S00061422720_V1
Stage 1 High Pressure Turbine Shroud
Figure 612/72-00-00-990-820-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 640
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
