#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
•
Wire wrapper
•
Wire cutters
•
Wire strippers
•
Crimp tool
•
Open-end wrench or hex tube screw driver
•
Fuse panel
•
Power cable (from fuse panel to assembly), #8
AWG, copper conductors, 194 degrees F [90
degrees C])
•
Ground cable #6 AWG stranded
•
Listed pressure dual-holes lugs suitable for #8
AWG copper conductors
Tools/Equipment
•
Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, refer to the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series
•
NTP-L30 Opening and Removing the Standard
Door of the NCS 2002 Shelf, on page 111
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
When installing or replacing the unit, the ground connection must always be made first and
disconnected last. Statement 1046
Warning
Hazardous voltage or energy may be present on DC power terminals. Always replace cover when
terminals are not in service. Be sure uninsulated conductors are not accessible when cover is in
place. Statement 1075
Warning
Cisco NCS 2000 Series Hardware Installation Guide
84
Connecting Power and Ground
DLP-L50 Connecting Office Power (DC) to the NCS 2002 Shelf (ANSI Only)
