While it is possible for one person to install an empty NCS 2015 shelf, if the NCS 2015 shelf is fully loaded,
then two people should install it. For ease of lifting, it is recommended that the shelf be empty. For information
on the NCS 2015 shelf weight, see the NCS 2015 Shelf Specifications, on page 473.
Mounting Multiple Shelves
Most standard 600 x 300 x 2200 mm racks can hold three NCS 2015 shelves, and a fuse and alarm panel. In
an ETSI rack, the brackets are mounted only in the middle position.
The NCS 2015 shelves can be mounted above each other without any space between the shelves.
NTP-L47 Mounting NCS 2015 Shelf
This procedure helps in mounting the NCS 2015 shelf.
In an ANSI and ETSI rack, the chassis can
be installed in the middle position.
Note
Purpose
•
#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
•
ETSI only:
◦
16 M6 x 20 mm pan-head Phillips
mounting screws
•
ANSI only:
◦
16 #12-24 x 0.50 inch pan-head Phillips
mounting screws
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
NTP-L48 Mounting Brackets on NCS 2015 Shelf for
ANSI Rack Configuration, on page 303
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Cisco NCS 2000 Series Hardware Installation Guide
317
Mounting the Cisco NCS 2015 Shelf
Mounting Multiple Shelves
