NCS 2015NCS 2006NCS 2002User Supplied Material
VoltmeterVoltmeterVoltmeterVoltmeter
Wire cuttersWire cuttersWire cuttersWire Cutters
Wire strippersWire strippersWire strippersWire Strippers
Wire wrapperWire wrapperWire wrapperWire Wrapper
Ring runs are not provided by Cisco and can hinder side-by-side shelf installation where space is limited.Note
Ordering Solutions for NCS 2002, NCS 2006, and NCS 2015
Two ordering solutions for the NCS 2002 shelf are offered. Select one of these solutions:
•
Shelf that is preinstalled with all the ancillary units such as fan tray assembly and power module.
•
Shelf that is not preinstalled with the ancillary units but can be ordered separately.
In both the ordering solutions, the front door is preinstalled with the NCS 2002 shelf.Note
Two ordering solutions for the Cisco NCS 2006 shelf are offered. Select one of these solutions:
•
Shelf assembly that is preinstalled with all the ancillary units such as fan tray assembly, LCD unit, power
module and NCS 2006 ECU.
•
Shelf assembly that is not preinstalled with the ancillary units but can be ordered separately.
One ordering solution for the Cisco NCS 2015 shelf is offered.
•
Shelf assembly that is not preinstalled with the ancillary units but can be ordered separately.
Card Slot Requirements
The cards have electrical plugs at the back that plug into electrical connectors on the shelf backplane. When
the ejectors are fully closed, the card plugs into the assembly backplane.
NCS 2002
The NCS 2002 shelf assemblies have 3 card slots numbered sequentially from bottom to top. Slot 1 is reserved
for control cards (TNC, TNCE, TSC, or TSCE). Slot 2 and Slot 3 are dedicated for common line cards.
Cisco NCS 2000 Series Hardware Installation Guide
16
Preparing to Install the Cisco NCS 2002, NCS 2006, and NCS 2015 Shelf
Ordering Solutions for NCS 2002, NCS 2006, and NCS 2015
