Stop. You have completed this procedure.
Figure 233: Cisco Catalyst Switch 3560 for NCS 2015 Multishelf Node
NTP-L64 Connect the ONS 15454 Node Controller to an
MS-ISC-100T Card
Use this procedure to connect a ONS 15454 node
controller to two MS-ISC-100T cards.
Purpose
5.9 in. (0.15 m) CAT-5 LAN cable (2)
19.69 in. (0.5 m) CAT-5 LAN cable (1)
84 in. (2.13 m) EAP cables (2)
Tools/Equipment
Cisco NCS 2000 Series Hardware Installation Guide
415
Multishelf Management
NTP-L64 Connect the ONS 15454 Node Controller to an MS-ISC-100T Card
To Next Page
