Procedure
Step 1
Place the narrow side of the 23-inch mounting bracket flush against the shelf. The wider side of the mounting
bracket should be towards the front of the shelf.
Step 2
Align the mounting bracket screw holes against the shelf screw holes.
Step 3
Insert the screws and tighten them to a torque value of 11.5 in-lb (1.3 N-m).
Step 4
Repeat steps 1 through 3 for mounting the bracket on the opposite side.
Step 5
Return to your originating procedure (NTP).
DLP-L37 Mounting the Bracket with Air Deflectors (Front-to-Back) on the NCS
2002 Shelf for ANSI Rack Configuration
This task mounts the 23-inch brackets with air
deflectors (front-to-back) on the NCS 2002 shelf for
ANSI rack configuration.
In an ANSI rack, the air deflectors can be
mounted only in the 23-inch rack
configuration and in the front position of the
chassis.
Note
Purpose
•
#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
Tools/Equipment
NTP-L41 Unpacking and Inspecting the Shelf, on
page 20.
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Use only the fastening hardware provided with the NCS 2002 to prevent loosening, deterioration, and
electromechanical corrosion of the hardware and joined material.
Caution
Cisco NCS 2000 Series Hardware Installation Guide
49
Mounting the Cisco NCS 2002 Brackets
DLP-L37 Mounting the Bracket with Air Deflectors (Front-to-Back) on the NCS 2002 Shelf for ANSI Rack Configuration
