NTP-L51 Opening and Removing the Door of the NCS 2015 Shelf
This procedure opens and removes the door of the
NCS 2015 shelf.
Purpose
#2 Phillips Dynamometric screwdriverTools/Equipment
•
NTP-L48 Mounting Brackets on NCS 2015
Shelf for ANSI Rack Configuration, on page
303
•
Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, see the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series .
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The NCS 2015 shelf has an ESD plug input and is shipped with an ESD wrist strap. The ESD plug input
is located on the outside of the shelf on the right side. It is labeled “ESD” on the top and bottom. Always
wear an ESD wrist strap and connect the strap to the ESD plug when working on the NCS shelf. For
detailed instructions on how to wear the ESD wristband, see the Electrostatic Discharge and Grounding
Guide for Cisco NCS 2000 Series .
Note
Procedure
Step 1
Turn the knob to unlock the door.
Step 2
Swing the door open.
Step 3
Remove the ground cable from the shelf by removing the screw.
Step 4
Pull the top hinge pin holding the door to the chassis, in the downward direction.
Step 5
Lift the door out of the bottom hinge pin to remove the door from its hinges.
Stop. You have completed this procedure.
Cisco NCS 2000 Series Hardware Installation Guide
381
Installing the Cisco NCS 2015 Door and Other Modules
NTP-L51 Opening and Removing the Door of the NCS 2015 Shelf
