• “SHELF-COMM-FAIL” alarm is present - if this alarm does occur, the user can still proceed with the
mode conversion after resetting the active controller (TNCS).
•
any SSC is in limited state
This task enables the user to change the system mode
using the LCD module.
Purpose
NoneTools/ Equipment
As neededRequired/ As Needed
OnsiteOnsite/ Remote
Superuser onlySecurity Level
Procedure
Step 1
On the front panel, just below the LCD display, are three buttons, marked Slot, Status and Port.
Step 2
Repeatedly press the Port button to reach the Mode Change Configuration option from the main menu.
Step 3
Press the Status button to enter the Mode Change Configuration option.
Controller
Status = Mode cfg
Step 4
On the left hand side of the LCD display (the Slot button), the ANSI option is displayed. On the right hand
side of the LCD display, (the Port button) , the ETSI option is displayed.
Step 5
Select the required mode, either by pressing the Slot or Port button. If the user by mistake, chooses the current
mode, a relevant error message is displayed.
Step 6
On successful mode change, the LCD display reads:
Changing mode...
TNC may reset
Step 7
After successful mode change, the control card automatically reboots. In case of multishelf configuration, all
the control cards reboot simultaneously.
Step 8
To verify mode change, go to the System Mode area in the General tab of CTC and confirm the current
mode. Alternatively, use the rtrv-ne-gen TL1 command to check the current mode.
Multishelf Management in Cisco NCS 2015
The following sections describe the various multishelf LAN topologies supported in Cisco NCS 2015.
Cisco NCS 2000 Series Hardware Installation Guide
411
Multishelf Management
Multishelf Management in Cisco NCS 2015
