Step 2
Loosen the screw and move it to the right position (towards the DC silk-screen text).
Step 3
Tighten the screw again to a torque value of 4 in-lb (0.45 N-m).
Step 4
Return to your originating procedure (NTP).
DLP-L3 Mounting the Reversible Brackets on the NCS 2006 Shelf for ANSI Rack
Configuration
This task installs the reversible mounting brackets on
the NCS 2006 shelf for ANSI rack configuration.
Purpose
•
#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Use only the fastening hardware provided with the NCS 2006 to prevent loosening, deterioration, and
electromechanical corrosion of the hardware and joined material.
Caution
When mounting the NCS 2006 in a frame with a nonconductive coating (such as paint, lacquer, or enamel)
either use the thread-forming screws provided with the NCS 2006 ship kit, or remove the coating from
the threads to ensure electrical continuity.
Caution
In an ANSI rack, reversible mounting brackets (19-inch or 23-inch) are used to install the shelf. The
mounting brackets can be installed in the front or the middle position of the chassis.
Note
Cisco NCS 2000 Series Hardware Installation Guide
169
Mounting the Brackets on NCS 2006 Shelf
DLP-L3 Mounting the Reversible Brackets on the NCS 2006 Shelf for ANSI Rack Configuration
