Step 5
Align the screw holes on the left front air deflector with the screw holes on the left side of the chassis.
Step 6
Insert the screws and tighten them to a torque value of 11.5 in-lb (1.3 N-m).
Step 7
Return to your originating procedure (NTP).
DLP-L7 Mounting the Bracket with Air Deflectors (Front-to-Back) on the NCS
2006 Shelf for ETSI Rack Configuration
This task installs the bracket with air deflectors
(front-to-back) on the NCS 2006 shelf for ETSI rack
configuration.
The air deflectors can be installed only in
the front position of the chassis.
Note
Purpose
•
#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Use only the fastening hardware provided with the NCS 2006 to prevent loosening, deterioration, and
electromechanical corrosion of the hardware and joined material.
Caution
Procedure
Step 1
Place the right front air deflector flush against the right side of the chassis (see Diagram 1 of the figure below).
Step 2
Align the screw holes on the right front air deflector with the screw holes on the right side of the chassis.
Step 3
Insert the screws and tighten them to a torque value of 11.5 in-lb (1.3 N-m).
Step 4
Place the left back air deflector flush against the chassis as shown in Diagram 2 of the figure below.
Do not mount the left back deflector (exhaust air deflector), if these cards are to be installed in the NCS 2006
shelf:
Cisco NCS 2000 Series Hardware Installation Guide
179
Mounting the Brackets on NCS 2006 Shelf
DLP-L7 Mounting the Bracket with Air Deflectors (Front-to-Back) on the NCS 2006 Shelf for ETSI Rack Configuration
