DLP-L17 Replacing NCS2006-DC20 With NCS2006-DC Power Module
This procedure replaces the NCS2006-DC20 with
NCS2006-DC power module.
Purpose
#2 Phillips Dynamometric screwdriverTools/Equipment
NTP-L5 Opening and Removing the Standard Door
of the NCS 2006 Shelf , on page 252.
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The procedure to replace the NCS2006-DC20 power module with NCS2006-DC40 power module is the
same as this procedure. The NCS2006-DC40 power module uses NCS2006-DCCBL2-L= and
NCS2006-DCCBL2-R= cables.
Note
While changing the power modules from NCS2006-DC20 to NCS2006-DC and vice-versa, the NCS 2006
shelf can temporarily work with both NCS2006-DC and NCS2006-DC20 power modules installed.
However, during regular operation, the shelf must either have the NCS2006-DC or NCS2006-DC20 power
module, but not both.
Caution
Always use the supplied ESD wristband when working with a powered NCS 2006. For detailed instructions
on how to wear the ESD wristband, see the Electrostatic Discharge and Grounding Guide for Cisco NCS
2000 Series .
Caution
Procedure
Step 1
Disconnect the power source and remove the power connections from the standby power module (installed
in slot B).
Step 2
Unscrew the holding screw that secures the NCS2006-DC20 power module.
Step 3
Pull the NCS2006-DC20 power module clear from the NCS2006 chassis.
Step 4
Install the NCS2006-DC power module as described in the DLP-L15 Installing the DC Power Module in the
NCS 2006 Shelf, on page 285.
Step 5
Install power on the NCS2006-DC power module as described in the NTP-L12 Installing Power and Ground
to the NCS 2006 Shelf , on page 200.
Cisco NCS 2000 Series Hardware Installation Guide
291
Installing the Cisco NCS 2006 Door and Other Modules
DLP-L17 Replacing NCS2006-DC20 With NCS2006-DC Power Module
